Engine 5502

Type 1 Engine*

Twin to Engine 5501 at Station 1


Darley Build Number:   2037-1998


Mechanical

  • 1998 W .S. Darley custom pumper

  • 1871-series HME chassis

  • 450 HP Cummins diesel engine

  • 6-speed Allison automatic transmission

  • electromagnetic driveline retarder

  • all-wheel drive

  • anti-lock brakes

  • hot-shift PTO (power take off)

  • instant deployment chains

Fire Attack

  • Compressed-air foam system (CAFS)

  • PTO-driven 1250 gpm Darley single-stage water pump

  • 200 CFM PTO-driven air compressor

  • 1,200 gallon water tank

  • 30 gallon Class-A foam tank

  • 2,000 feet of 3" supply line

  • (2) 1-3/4" preconnected attack lines

  • (2) 2-1/2" preconnected attack lines

  • 1,000 gpm deck gun

  • 2,400 gallon portable pond

Additional Equipment

  • 4 SCBA (Self-Contained Breathing Apparatus) units

  • 4 spare SCBA bottles

  • ladder complement

  • wildfire tools

  • extinguishers

  • 5KW generator

  • rotary saw

  • entry and overhaul tools

  • initial response EMS equipment

* NW CG Type 1 Firefighting Engines or “Pumpers” have at minimum: a 1000+ gallon per minute @ 150 psi pump capacity; 400+ gallon tank capacity; 1200 ft 2.5 inch hose; 400 ft 1.5 inch hose; and can carry 4 personnel.
